XBY4000JG Microcomputer Controlled Electro Hydraulic Servo Manhole Cover Pressure Testing Machine

Product Name:Microcomputer Controlled Electro Hydraulic Servo Manhole Cover Pressure Testing Machine

Product model:XBY4605JG、XBY4106JG

Product Overview:

This testing machine is mainly used for compressive strength testing of manhole covers. This testing machine adopts advanced technologies such as high-precision servo pumps with a wide speed range and computer digital control, which can automatically and accurately measure and control the entire testing process of loading and unloading of the testing machine. Various experimental parameters are controlled, measured, displayed, processed, and printed by computers, with high integration and easy use.



This machine meets the requirements of CJ/T3012-93 "Cast Iron Inspection Manhole Cover"

JC/T889-2001 "Steel Fiber Reinforced Concrete Inspection Manhole Cover"

CJT121-2000 "Inspection manhole cover for recycled resin composite materials"

CJ/T211-2005 "Inspection manhole covers for polymer based composite materials"

The testing requirements specified in standards such as GB/T2611-92 General Technical Requirements for Testing Machines and JB/T8612-97 Microcomputer Controlled Electro Hydraulic Servo Universal Testing Machine.


model

XBY4605JG

XBY4106JG

Maximum test force

600KN

1000KN

Accuracy level

1级

Measurement range

2%-100%

Force accuracy

+1% better than the indicated value

Speed range

0.01mm/min-500 mm/min

Speed accuracy

+1% better than the indicated value

Compression accuracy

+1% better than the indicated value

Rigid adjustment pad size

φ356mm、250x250x150mm、250x250x75 mm

Workbench size

The effective width of the two columns is 1200mm, and the distance between the front and rear of the workbench is 1200mm (can be customized according to customer requirements)

The height from the bottom of the workbench to the ground

350mm

External dimensions

1600*1400*2000mm

Power Supply

380V/50HZ

weight

3300KG

work environment
