XBZ3000B series digital display semi-automatic pendulum impact testing machine

Product name: XBZ3000B series digital display semi-automatic pendulum impact testing machine

Product models: XBZ300B, XBZ500B

Product Function Overview: This machine is equipped with a LCD digital display controller, which has dual control and dual display functions. The LCD digital display controller adopts PLC control and measurement, and calculates the rebound angle of the pendulum based on the rebound angle of the punched sample measured by rotary encoder, automatically displaying the rebound angle β The absorption work done by the pendulum on the sample, as well as the impact toughness ak value, can also be printed with the addition of a micro punch, including test data, average work of three tests, and test time and serial number.

The main body of this machine is made of cast steel material, which makes it rigid and stable throughout the entire testing process, has strong impact resistance, is not easily deformed, the test results are accurate, and the service life is long. Adopting a high torque clutch and a high-power motor makes it more stable and vibration free during swing and release.

Related execution standards:

This machine is developed and produced in accordance with the domestic standard GB/T 3808-2002 "Inspection of Pendulum Impact Testing Machines". It conducts impact tests on metal materials in accordance with the national standard GB/T 229-2007 "Charpy Pendulum Testing Method for Metal Materials" and complies with JJG 145-2007 "Verification Regulations for Pendulum Impact Testing Machines". If the structural form is changed and relevant parts are replaced, the requirements of international standards such as ASTM E23, EN 10045, ISO 148, and ISO 83 can be met simultaneously.
